42L Single Well Gas Pasta Cooker – 14kW from Mareno

42L Single Well Gas Pasta Cooker

The 42L single well gas pasta cooker provides a dedicated boiling station for pasta, noodles and selected food products in restaurants, hotels, central kitchens and catering facilities.

The appliance has a compact 40cm freestanding design. Its body is manufactured from AISI 304 stainless steel, while the deep-drawn cooking tank is made from polished AISI 316 stainless steel.

It operates on LPG at the stated 30/50mbar pressure and has a gas power rating of 14kW.

42-Litre Water Capacity

The single tank pasta cooking machine provides one tank with a water capacity of 42 litres.

It can be used for:

• Pasta and macaroni.
• Noodles.
• Selected dough products suitable for boiling.
• Vegetables cooked in water.
• Commercial products requiring boiling or blanching.

Actual output depends on the product type, portion size, number of baskets used and permitted water level.

AISI 316 Stainless Steel Tank

The stainless steel restaurant pasta cooker features a deep-drawn cooking tank manufactured from polished AISI 316 stainless steel.

The tank has a radiused bottom, helping operators reach the corners and base during cleaning and reducing sharp internal areas where food residue may collect.

Tank Design Benefits

• Polished internal surface.
• Radiused bottom for easier cleaning.
• Better access to the tank base.
• Reduced sharp internal corners.
• Suitable for repeated commercial use.
• Supports daily boiling operations.

305×510×285mm Tank Dimensions

The internal tank dimensions are:

• Width: 305mm.
• Depth: 510mm.
• Height: 285mm.

The deep tank provides useful cooking capacity within a compact 40cm-wide appliance.

Compatible pasta baskets and accessories should be selected according to the tank dimensions and appliance model.

Temperature Range from 0°C to 100°C

The cooker operates within a temperature range from 0°C to 100°C.

This range supports heating the water and maintaining boiling conditions for pasta preparation.

The gas setting should be adjusted according to the water quantity, production volume and required boiling level.

Gas Valve Heating Control

Heating is controlled by a gas valve.

The valve regulates the gas supply according to the required operating level. Only a qualified technician should adjust or service the gas-control components.

Piezoelectric Pilot Ignition

The Mareno gas pasta cooker provides automatic pilot-burner ignition by means of a piezoelectric device.

This system supports startup without a separate external ignition source when the manufacturer’s lighting procedure is followed.

If ignition fails or the pilot flame repeatedly goes out, the gas supply should be closed and the appliance inspected by a qualified technician.

Empty-Tank Heating Protection

Safety is provided by a pressure switch that prevents heating if the tank is empty.

This system helps prevent burner operation when an adequate quantity of water is not present in the tank.

Safe Operating Guidelines

• Confirm that the tank contains water before ignition.
• Never operate the cooker with an empty tank.
• Monitor the water level during service.
• Refill according to the operating instructions.
• Stop using the appliance if the safety system does not operate correctly.
• Arrange inspection by a qualified technician when required.

Protected Water Tap

The appliance includes a water tap located in a protected zone.

The tap provides convenient water filling close to the cooking tank, while its protected position helps reduce accidental impact during operation.

The filling process should be monitored to prevent overfilling.

14kW Commercial Pasta Boiler

The 14kW commercial pasta boiler provides the gas power required to heat a 42-litre water tank in a commercial environment.

Installation requires:

• A gas line suitable for the stated power.
• A compatible gas-pressure regulator.
• An accessible shut-off valve.
• Adequate kitchen ventilation.
• Leak testing before operation.
• Installation by a qualified gas technician.

LPG Operation

The cooker is designed for LPG operation at the stated 30/50mbar pressure.

It should not be connected to another gas type or pressure unless approved by the manufacturer and converted by an authorised technician.

AISI 304 Stainless Steel Body

The appliance body is manufactured from AISI 304 stainless steel for professional food-service environments.

Its smooth exterior supports routine wiping and cleaning, while the stainless steel finish coordinates with other commercial kitchen appliances.

Compact 40cm Freestanding Design

The 40cm freestanding pasta cooker has the following external dimensions:

• Width: 40cm.
• Depth: 92cm.
• Height: 90cm.

Its compact width allows it to be installed beside ranges, fryers and other commercial cooking equipment.

The unit should be positioned on a stable and level floor capable of supporting its 63kg weight, with sufficient access for operation, cleaning and servicing.

Main Product Features

• One 42-litre water tank.
• Deep-drawn AISI 316 stainless steel tank.
• AISI 304 stainless steel body.
• Polished tank surface.
• Radiused tank bottom.
• Temperature range from 0°C to 100°C.
• Piezoelectric pilot ignition.
• Heating controlled by gas valve.
• Pressure-switch protection against empty-tank heating.
• Water tap in a protected zone.
• LPG operation.
• Gas pressure of 30/50mbar.
• Gas power of 14kW.
• Compact 40cm freestanding design.
• Suitable for commercial restaurant kitchens.

Suitable Commercial Applications

Italian Restaurants

The cooker provides a dedicated station for preparing pasta portions during service.

Hotels and Central Kitchens

It supports repeated pasta-boiling batches during daily production.

Commercial Restaurants

The appliance can prepare pasta, noodles and selected vegetables requiring boiling.

Catering Operations

Its 42-litre tank supports repeated commercial boiling cycles.

Compact Kitchens

The 40cm width allows the appliance to be installed beside other professional cooking equipment.

Technical Specifications

• Product type: Freestanding single-well gas pasta cooker.
• Model: CP94G.
• Number of tanks: One.
• Water capacity: 42 litres.
• Body material: AISI 304 stainless steel.
• Tank material: Polished AISI 316 stainless steel.
• Tank design: Deep drawn with radiused bottom.
• Tank dimensions: 305×510×285mm.
• Temperature range: 0°C to 100°C.
• Ignition system: Piezoelectric pilot ignition.
• Heating control: Gas valve.
• Safety system: Pressure switch preventing empty-tank heating.
• Water tap: Located in a protected zone.
• Gas type: LPG.
• Gas pressure: 30/50mbar.
• Gas power: 14kW.
• Width: 40cm.
• Depth: 92cm.
• Height: 90cm.
• Weight: 63kg.

Why Choose This Gas Pasta Cooker?

This appliance is suitable for commercial kitchens requiring a dedicated pasta-boiling station within a compact 40cm width. Its AISI 316 tank, piezo ignition, dry-tank protection and protected water tap support organised daily cooking and cleaning.
